Gigabyte A520M AORUS ELITE DDR4 AMD Motherboard
Original price was: 9,330৳ .8,700৳ Current price is: 8,700৳ .
- Brand: Gigabyte
- Model: Gigabyte A520M Aorus Elite
- AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
- Smart Fan 5 Features
- Ultra-Fast NVMe PCIe 3.0 x4 M.2
- 5+3 Phases Pure Digital VRM Solution
- 03 years warranty
General
Model
Gigabyte A520M AORUS ELITE
Chipset
AMD A520
Form Factor
Micro ATX
Warranty
3 year
Country Of Origin
Taiwan
Made in/ Assemble
China
Compatibility
Sockets Supported
AM4
Supported CPU
AMD Ryzen 5000 Series/ AMD Ryzen 3rd Generation Processors with Radeon Graphics processors
Supported Operating System
Windows 10
Memory Support
Memory Type
DDR4
Memory MHz
AMD Ryzen 5000 series (4266(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133MHz), AMD Ryzen 3rd Gen (4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133MHz), AMD Ryzen 3rd Gen with Radeon Graphics (4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133MHz)
Memory Channel
Dual
Memory Slot
4
Memory Max.
128GB
Optane Memory Support
No
Graphics
Graphics
Integrated Graphics
Multi-GPU Support
No
PCI Express Slot
1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16, 2 x PCI Express x1 slots, supporting PCIe 3.0 (PCIEX1_1, PCIEX1_2)
CrossFire Support
No
Sli Support
No
Storage
Storage Interface
6.0Gb/s
M.2/SSD Expansion Slot
1
SATA Port
4 x SATA
Raid Support
0, 1, 10
Network & Connectivity
LAN Chipset
Realtek GbE LAN
LAN Speed (Mbps)
100/1000
Ports
USB Port
5 x USB3.2 Gen 1, 3 x USB2.0
DVI Port
1
HDMI Port
1
Audio
Audio Chipset.
Realtek ALC887
Audio Channel
2/4/5.1/7.1
Bios Information
BIOS Type
1 x 128 Mbit Flash
BIOS Model
AMI UEFI BIOS
BIOS Version
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Additional Info
Brand
Gigabyte
Chipset Brand
AMD
WiFi
No
Bluetooth
No
FireWire
No
TPM Port
Yes
COM Port
No
RGB Support
Yes
RGB Sync
RGB FUSION 2.0
RGB Connector
2 x RGB LED strip headers
Feature
AMD A520 AORUS Motherboard with Pure Digital VRM Solution, GIGABYTE Gaming LAN with Bandwidth Management, PCIe 3.0 x4 M.2, RGB FUSION 2.0, Smart Fan 5, Q-Flash Plus, Supports 3rd Gen AMD Ryzen Processors, Dual Channel ECC/ Non-ECC Unbuffered DDR4, 4 DIMMs, 5+3 Phases Pure Digital VRM Solution with Low RDS(on) MOSFETs, Ultra-Fast NVMe PCIe 3.0 x4 M.2 Connector, GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management, HDMI, DVI-D Ports for Multiple Display, Features High-Quality Audio Capacitors, RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips, Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP, Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card
Others
1 x CPU fan header, 2 x system fan headers, 2 x addressable LED strip headers, 2 x RGB LED strip headers, 1 x front panel header, 1 x front panel audio header, 1 x Trusted Platform Module (TPM) header, 1 x serial port header, 1 x Clear CMOS jumper, 1 x Q-Flash Plus button, 3 x audio jacks
